FI-S4P-HFE Allicdata Electronics
Allicdata Part #: 670-2873-ND
Manufacturer Part#:

FI-S4P-HFE

Price:

$ 2.19

Product Category: Connectors, Interconnects
Manufacturer: JAE Electronics
Description: CONN RCPT 1.25MM 4PO...
DataSheet: FI-S4P-HFE datasheetFI-S4P-HFE Datasheet/PDF
Quantity: 1288

AllICdata Limited--Hope to See You In 2018 EXPO ELECTRONICA !

click Me to Learn More
1 +: $ 2.21
10 +: $ 2.009
100 +: $ 1.722
500 +: $ 1.435
1000 +: $ 1.23
5000 +: $ 1.0906
Stock 1288Can Ship Immediately
$ 2190
Specifications
Series: FI
Packaging: Cut Strip
Part Status: Active
Connector Type: Receptacle
Contact Type: Male Pin
Pitch - Mating: 0.049" (1.25mm)
Number of Positions: 4
Number of Rows: 1
Row Spacing - Mating: --
Number of Positions Loaded: All
Style: Board to Cable/Wire
Shrouding: Shrouded - 4 Wall
Mounting Type: Surface Mount, Right Angle
Termination: Solder
Fastening Type: Friction Lock
Contact Length - Mating: --
Contact Length - Post: --
Overall Contact Length: --
Insulation Height: 0.071" (1.80mm)
Contact Shape: Square
Contact Finish - Mating: Gold
Contact Finish Thickness - Mating: --
Contact Finish - Post: Tin or Tin-Alloy
Contact Material: Copper Alloy
Insulation Material: Liquid Crystal Polymer (LCP), Glass Filled
Features: Solder Retention
Operating Temperature: -40°C ~ 80°C
Ingress Protection: --
Material Flammability Rating: UL94 V-0
Insulation Color: Beige
Current Rating: 1A per Contact
Voltage Rating: 200V
Mated Stacking Heights: --
Contact Finish Thickness - Post: --
Applications: --
